V Series
|
|
.png)
Description
Fuzetec V Series Metal Oxide Varistors (MOV) are designed for applications which require medium level of surge protection.
Maximun Allowable Voltage
AC Voltage Range 130 ~ 680V
DC Voltage Range 170~895V
DC Voltage Range 170~895V
Varistor Voltage
200V to 1100V DC
Peak Current for 8/20µS Current Wave
800 to 10000 A
Feature
RoHS compliant
Halogen-free series are available
Body size: Φ 05 ~ Φ 20mm
Halogen-free series are available
Body size: Φ 05 ~ Φ 20mm
Agency Recognition
| AGENCY | AGENCY FILE NUMBER |
 |
VZCA2.E515006 VZCA8.E515006 |
-
FMOV05-VMaximun Continuous Voltage:
AC Voltage Range 130 ~ 465V/ DC Voltage Range 170~615V
Varistor Voltage: 200V~750V DC
Peak Current for 8/20µS Current Wave: 800 A -
FMOV07-VMaximun Continuous Voltage:
AC Voltage Range 130 ~ 510V/ DC Voltage Range 170~670V
Varistor Voltage: 200V~820V DC
Peak Current for 8/20µS Current Wave: 1,800 A -
FMOV10-VMaximun Continuous Voltage:
AC Voltage Range 130 ~ 680V/ DC Voltage Range 170~895V
Varistor Voltage: 200V~1,100V DC
Peak Current for 8/20µS Current Wave: 3,500 A -
FMOV14-VMaximun Continuous Voltage:
AC Voltage Range 130 ~ 680V/ DC Voltage Range 170~895V
Varistor Voltage: 200V~1,100V DC
Peak Current for 8/20µS Current Wave: 6,000 A -
FMOV20-VMaximun Continuous Voltage:
AC Voltage Range 130 ~ 680V/ DC Voltage Range 170~895V
Varistor Voltage: 200V~1,100V DC
Peak Current for 8/20µS Current Wave: 10,000 A
