FRV Series - Radial Leaded PTC
|
|
.png)
Application
Line Voltage Power Supply, Transformer and Appliances
Feature
Low hold current, Solid state, Radial leaded product ideal for up to 265VAC/DC
Maximum Operation Current
0.05A~2.00A
Maximum Operating Voltage
240VAC/DC
Maximum Interrupt Voltage
265VAC/DC
Temperature Range
-40℃ to 85℃
Agency Recognition
| AGENCY | AGENCY FILE NUMBER |
 |
E211981 |
 |
E211981 |
 |
R50122733 |
Electrical Characteristics (23°C)
|
Part Number
|
Hold
Current |
Trip
Current |
Rated
Voltage |
Max
Current |
Max. Int.
Voltage |
Typical
Power |
Max Time to Trip
|
Resistance
|
|
|
IH, A
|
IT, A
|
VMAX, VAC/DC
|
IMAX, A
|
VMAX, V AC/DC
|
Pd, W
|
@ 5 x IH, S
|
Rmin
|
R1max
|
|
| FRV005-240F |
0.05
|
0.12
|
240
|
1.0
|
265
|
0.70
|
15.0
|
18.50
|
65.00
|
| FRV008-240F |
0.08
|
0.19
|
240
|
1.2
|
265
|
0.80
|
15.0
|
7.40
|
26.00
|
| FRV012-240F |
0.12
|
0.30
|
240
|
1.2
|
265
|
1.00
|
15.0
|
3.00
|
12.00
|
| FRV016-240F |
0.16
|
0.37
|
240
|
2.0
|
265
|
1.40
|
15.0
|
2.50
|
7.80
|
| FRV025-240F |
0.25
|
0.56
|
240
|
3.5
|
265
|
1.50
|
18.5
|
1.30
|
3.80
|
| FRV033-240F |
0.33
|
0.74
|
240
|
4.5
|
265
|
1.70
|
21.0
|
0.83
|
2.60
|
| FRV040-240F |
0.40
|
0.90
|
240
|
5.5
|
265
|
2.00
|
24.0
|
0.60
|
1.90
|
| FRV055-240F |
0.55
|
1.25
|
240
|
7.0
|
265
|
3.40
|
26.0
|
0.45
|
1.45
|
| FRV075-240F |
0.75
|
1.50
|
240
|
7.5
|
265
|
2.60
|
18.0
|
0.32
|
0.84
|
| FRV100-240F |
1.00
|
2.00
|
240
|
10.0
|
265
|
2.90
|
21.0
|
0.22
|
0.58
|
| FRV125-240F |
1.25
|
2.50
|
240
|
12.5
|
265
|
3.30
|
23.0
|
0.17
|
0.44
|
| FRV150-240F |
1.50
|
3.00
|
240
|
15.0
|
265
|
3.70
|
23.0
|
0.12
|
0.32
|
| FRV200-240F |
2.00
|
4.00
|
240
|
20.0
|
265
|
4.50
|
28.0
|
0.09
|
0.22
|
Thermal Derating
|
Temperature
|
-40℃
|
-20℃
|
0℃
|
23℃
|
30℃
|
40℃
|
50℃
|
60℃
|
70℃
|
85℃
|
|
Derating %
|
150%
|
134%
|
116%
|
100%
|
90%
|
81%
|
74%
|
65%
|
58%
|
44%
|
Product Dimension
Product Fig
 |
Fig1 Lead Size: 24AWG Ø 0.51 mm |
.png) |
Fig 2 Lead Size: 22AWG Ø 0.65 mm |
|
|
Fig3 Lead Size: 20AWG Ø 0.81 mm |
|
Fig 4 Lead Size: 22AWG Ø 0.81 mm |
|
Part Number
|
Fig.
|
A
|
B
|
C
|
D
|
E
|
F
|
|
Max
|
Max
|
Typ
|
Min
|
Max
|
Typ
|
||
| FRV005-240F |
1
|
8.3
|
10.7
|
5.1
|
7.6
|
3.8
|
1.6
|
| FRV008-240F |
1
|
8.3
|
10.7
|
5.1
|
7.6
|
3.8
|
1.6
|
| FRV012-240F |
1
|
8.3
|
10.7
|
5.1
|
7.6
|
3.8
|
1.6
|
| FRV016-240F |
1
|
9.9
|
12.5
|
5.1
|
7.6
|
3.8
|
1.6
|
| FRV025-240F |
2
|
9.6
|
17.4
|
5.1
|
7.6
|
3.8
|
1.8
|
| FRV033-240F |
2
|
11.4
|
16.5
|
5.1
|
7.6
|
3.8
|
1.8
|
| FRV040-240F |
2
|
11.5
|
19.5
|
5.1
|
7.6
|
3.8
|
1.8
|
| FRV055-240F |
3
|
14.0
|
21.7
|
5.1
|
7.6
|
4.1
|
1.9
|
| FRV075-240F |
3
|
11.5
|
23.7
|
5.1
|
7.6
|
4.8
|
1.9
|
| FRV100-240F |
4
|
18.7
|
24.4
|
10.2
|
7.6
|
5.1
|
1.9
|
| FRV125-240F |
4
|
21.2
|
27.4
|
10.2
|
7.6
|
5.3
|
1.9
|
| FRV150-240F |
4
|
23.4
|
30.9
|
10.2
|
7.6
|
5.3
|
1.9
|
| FRV200-240F |
3
|
24.9
|
33.8
|
10.2
|
7.6
|
6.1
|
1.9
|
